RS-232 Commands
Code Function Operation
Ethernet
Defines IP Operation
- Use “>” symbol before each command
- End with carriage return to send
IP IP Address IP returns the current MAC address, Ethernet firmware
version, current IP address, subnet mask, and gateway.
Response example (S or D at end of IP signifies DHCP or
Static address):
$MAC=0014C8000201
$IP=192.168.001.232S IG=000.000.000.000
IM=255.255.255.000 IY=1
IP = xxx.xxx.xxx.xxx Defines IP address, then sends status
(0.0.0.0 = DHCP)
IG IP Gateway IG = Returns current MAC address, Ethernet firmware
version, current IP information
IG = xxx.xxx.xxx.xxx Defines IP gateway, then sends status
IM IP Subnet Mask IM = Returns current MAC address, Ethernet firmware
version, current IP information
IM = xxx.xxx.xxx.xxx Defines IP subnet mask, then sends
status
IY= IP Mode IY Returns current mode
IY=1 Static (default)
IY=2 DHCP
IX= Telnet Port (RS-232) IX Returns current Telnet port for RS-232 (4001 default)
IX=xxxxx Defines Telnet port
Telnet port for setup commands fixed at 23
RS-232
Defines RS-232 Port Properties
R5= Baud Rate 0=300 5=9600 (default)
1=600 6=19.2K
2=1200 7=38.4K
3=2400 8=57.6K
4=4800 9=115.2K
R6= COM 0=8,N,1 (default)
1=8,0,1 6=7,0,1
2=8,E,1 7=7,E,1
3=8,N,2 8=7,N,2
4=8,M,1 9=7,M,1
5=8,S,1 10=7,S,1
Terminal Communication Commands
EF Echo Off Characters received will not be re-transmitted (power up default).
EN Echo On Characters received will be re-transmitted.
Example: ‘>EN’ Characters received will be re-transmitted.
ID Product ID Returns the product model number and firmware version.
Z! Zap Reconfigures unit for all factory default settings.
