Contemporary Research 23
ICC2-ATSC
Command
Description
Tuning
Input
EI
“$A5,,3, ‘EI’,” (7 bytes)
Sets the input for controlled projector or display. See Input list in ER.
Input Ring
ER
“$A5,,
Sets a list of inputs that are cycled by the Input command on the IC-IR remote or
KK command. Follow the standard list of inputs below, check with CR Support on
which are available for your make and model of video display.
1 Video1
11 DVI/HDMI1
2 Video2
12 DVI/HDMI2
3 Video3
13 DVI/HDMI3
4 S-Video1
14 DVI/HDMI4
5 S-Video2
15 DVI/HDMI5
6 Component1
16 TV
7 Component2
17 TV2
8 RGB1
18 1394
9 RGB2
19 Memory stick
10 RGB3/DTV
Ex: “$A5,,6,’ER’, 1,4,8,11” sets ring to Inputs 1, 4, 8 and 11.
Text
Write Text
DM “$A5,,
(variable bytes)
Clears current text, displays text message over video (default) or blank
background. The built-in character generator can accept up to 40 characters of
text (including carriage returns), 28 characters per line. Use a hex $0D or decimal
13 in the text as a carriage return, which will advance CG to the next line, first
space on the right.
Start Line - 1-9
Text Color - 1-7= White
Text Background Color – 0-7=Transparent (no background)
Full screen background – 0=normal insert over video
Size and Shadow – 0-3=small text with drop shadow
Time-Out – 0=15-second display, 1=persistent
Persistent text stays on screen until the next DM, or new Menu or channel.
Ex1: “$A5,,10,‘DM’, 2,7,0,0,1,0,’TEST’ ” displays the word TEST on the
second line, white text, inserted over video, small size with drop shadow, and
timing out after 15 seconds.
Ex2: “$A5,,2,‘DM’ ” clears on-screen display, also clears persistent text
The ATSC uses white text and clear backgrounds when it receives a Text or
Background Color parameter between 1 and 7, and accepts values 0-3 for text size
and shadow. This allows compatibility with Smart TVs mixed in the same system
that can display other colors and fonts.
Return
EB “$A5,,2,’EB’ ” (6 bytes)
Moves cursor down to the first column of the next row.
Text Timeout
DQ “$A5,,3,’DQ’,
Sets screen timeout to specified time in seconds (1-254). If time is 0 or 255, any
text on the screen will persist indefinitely, or until cleared.
