Front panel programming commands – Contemporary Research 232-STS User Manual

Page 7

background image

Contemporary Research

7

232-STS Stereo S-Video TV Tuner

Mode

0-9

Parameters

Mode

10+ Parameters

RF Tune

0.0

0.1

0.2

0.3

CATV

Broadcast

HRC

IRC

Caption Type

10.0

10.1

10.2

Captioning off (default)

Captioning on

Captioning on with mute

Baud Rate

1.1

1.2

1.3

1.4

1.5

1.6

1.7

300

600

1200

2400

4800

9600

19200

Caption Mode

11.1

11.2

11.3

11.4

11.X

1=Caption 1 (default)

2=Caption 2

3=Caption 3

4=Caption 4

5-8= Text 1-4 (rarely used)

Unit Number

2.1

2.2

2.3

2.x

One

Two

Three

Four – Nine

Video Detect

12.0

12.1

12.2

12.3

AV mutes when video lost*

Only audio mutes*

Only video mutes*

No AV mute

Not Used

3.0

AV Status

13.0

13.1

13.2

13.3

No AV status (default)

Stereo/Mono status only

Video Loss status only

Both status sent

Panel Lockout

4.0

4.1

4.2

4.3

4.4

4.5

4.6

4.7

None

Channel up/dwn

Volume up/dwn

Channel & Volume up/dwn

Mute A/V

Channel up/dwn & Mute A/V

Volume up/dwn & Mute A/V

All

Label Mode

14.0

14.1

14.2

14.3

None

Alpha only

Numeric only

Both

Power-up Volume

5.0

5.X

Restore previous level

1 – 63 sets volume level

Firmware Version

6.40 Ex: Version 4.0 - Press and hold

Channel Up, then Mute AV to

restore tuner to default settings

Audio Decode

7.0

7.1

7.2

7.3

Mono both channels

Left/right stereo

Mono/SAP

SAP/SAP

Bass Gain

8.0

8.X

-12 dB bass level

0-19 sets bass

-12 to 16.5dB

Treble Gain

9.0

9.X

-12 dB treble level

0-8 sets treble,

-12 to 12 dB

*Audio is always unmuted

when external AV inputs are

selected

Bass Level Settings

Level

Gain (dB)

Level

Gain (dB)

19

16.5

9

1.5

18

15.0

8

0

17

13.5

7

-1.5

16

12.0

6

-3.0

15

10.5

5

-4.5

14

9.0

4

-6.0

13

7.5

3

-7.5

12

6.0

2

-9.0

11

4.5

1

-10.5

10

3.0

0

-12.0

Treble Level Settings

Level

Gain (dB)

8

12

7

9

6

6

5

3

4

0

3

-3

2

-6

1

-9

0

-12
