Typical: [Attention] [Unit#] [data ...data] [cr] [lf]
232-STS status response strings contain ASCII characters similar to those used for the same functions in
command strings. An ASCII 'carriage return' and „line feed' follow each response string. Functions shown as N/A
are not applicable; characters will appear in status strings as lower-case x.
Channel/Source Status Response String (T):
Start Unit CMD Power Channel Video Mute N/A Video Present
1-9 U=On
M=Off
Current Channel
3 digits
U=Unmuted
M=Mute
2
digits
N=No Video
Y=Video
< 1 T U 008 U xx Y
Audio Status Response String (V):
Start Unit CMD Power Volume Volume Mute Stereo
1-9 U=On
M=Off
0-63
2 digits
U=UnMuted
M=Mute
S=Stereo
M=Mono
< 1 V U 63 U S
Front Panel Mode Status Response String (S):
Start Unit CMD Audio Mode Tune Mode Lockout Bass Treble
1-9 0=Mono/Mono
1=Stereo
2=Mono/SAP
3=SAP/SAP
0-3 0-9 0-9
2 digits
0-8
< 1 S 1 0 1 08 4
Q Mode Response String (Q):
Start Unit CMD Q0 Q1 Q2 Q3 Q4 N/A
1-9 0-2 1-8 0=AV Muted
2=Video Muted
0-3 0-3 5 digits
< 1 Q 2 1 0 0 x xxxxx
