NOTES:
1.
Unit tonnage rating conditions: 44
o
F leaving chilled water temperature, 85
o
F entering condenser water temperature, fl ow rates are 3 GPM per ton through the condenser
with a fouling factor of .00025 and 2.4 GPM per ton through the evaporator with a .0001 fouling factor.
2.
Quick Select Table is based on a maximum of fi ve modules. Multiple banks can be selected for additional project capacity.
3.
Ratings are based on R-22 with a 10
o
F drop in the evaporator and a 10
o
F rise in the condenser.
4.
“IPLV” integrated part load value is based on ARI Standard 550/590-1998.
5.
RLA. Rated Load Amps are calculated as per UL1995.
6.
MCA. Minimum Circuit Ampacity: 125% of the RLA of the largest compressor motor plus 100% of the RLA (or FLA) of all other concurrent motors and/or electrical loads.
7.
MOP. Maximum Overcurrent Protection or Max.Fuse Sizing: Rounded down from 225% of the RLA of the largest compressor motor plus 100% of the RLA (or FLA)
of all other concurrent electrical loads.
8.
Disconnect Switch Sizing: Rounded down from 150% of the sum of 100% of the RLA (or FLA) of all concurrent motor loads plus any other concurrent electrical loads.
9.
MOP Fusing Device and Disconnect Switch Device supplied by others. These are recommended values for electrical power protection of combined modules selected.
10. Combined module width does not include fl ange connection gaskets (1/8"), nor blank off plate fl anges (1 1/2") each.
ClimaCool Quik Select Table
Models 30, 50 & 65 - FLEX Series
X
208/230 Volt & 460 Volt
16
Project ClimaCool Total Modules Combined Performance ”IPLV” Electrical Data@ Electrical Data@ Combined Total
Tons Modules Full Load Data@ 100% Operation Part Load Effi ciency 460V-3ph-60hz 208-230V-3ph-60hz Module Oper.
FLEX Models Unit Unit Unit Effi ciency@Full Load IPLV IPLV IPLV RLA
5
MCA
6
MOP
7
RLA
5
MCA
6
MOP
7
Width
10
Weight
30
50
65
Tons kWi kW/ton EER COP kW/ton EER COP Lbs.
1
0
0 32.1 23.0 0.72 16.7 4.90 0.60 20.2 5.91 41.6 46.8 60
70
92 103.5 125 150 2'-5.5" 1825
40
0
1
0
51.4 36.9 0.72 16.7 4.90 0.60 19.9 5.82 64.4 72.4 100 100 142.3 160.1 225 225 2'-9.5" 2163
50
0
1
0
51.4 36.9 0.72 16.7 4.90 0.60 19.9 5.82 64.4 72.4 100 100 142.3 160.1 225 225 2'-9.5" 2163
60
0
0
1
65.3 46.8 0.72 16.7 4.90 0.59 20.3 5.95 82.8 93.2 125 125 183.1 206 250 300 2'-9.5" 2280
65
0
0
1
65.3 46.8 0.72 16.7 4.90 0.59 20.3 5.95 82.8 93.2 125 125 183.1 206 250 300 2'-9.5" 2280
70
0
0
1
65.3 46.8 0.72 16.7 4.90 0.59 20.3 5.96 82.8 93.2 125 125 183.1 206 250 300 2'-9.5" 2280
80
1
1
0
83
60 0.72 16.7 4.90 0.59 20.4 5.96 106 114 125 175
234 252 300 400
5'-3" 3988
90
1
0
1
97
70 0.72 16.7 4.90 0.59 20.4 5.99 124 135 175 200
275 298 350 450
5'-3" 4105
100
1
0
1
97
70 0.72 16.7 4.90 0.59 20.4 5.99 124 135 175 200
275 298 350 450
5'-3" 4105
110
0
1
1
117
84 0.72 16.7 4.90 0.59 20.5 6.01 147 158 175 225
325 348 400 500
5'-7" 4443
120
0
1
1
117
84 0.72 16.7 4.90 0.59 20.5 6.01 147 158 175 225
325 348 400 500
5'-7" 4443
130
0
0
2
131
94 0.72 16.7 4.90 0.58 20.7 6.08 166 176 200 250
366 389 450 600
5'-7" 4560
140
1
1
1
149 107 0.72 16.7 4.90 0.58 20.8 6.10 189 199 225 300
417 440 500 700 8'-0.5" 6268
150
1
1
1
149 107 0.72 16.7 4.90 0.58 20.8 6.10 189 199 225 300
417 440 500 700 8'-0.5" 6268
160
1
0
2
163 117 0.72 16.7 4.90 0.58 20.9 6.12 207 218 250 350
458 481 500 700 8'-0.5" 6385
170
0
2
1
168 121 0.72 16.7 4.90 0.58 20.8 6.11 212 222 250 350
468 491 500 700 8'-4.5" 6606
180
0
1
2
182 131 0.72 16.7 4.90 0.57 20.9 6.13 230 240 250 350
509 532 600 800 8'-4.5" 6723
190
0
0
3
196 140 0.72 16.7 4.90 0.57 21.0 6.16 248 259 300 400
549 572 600 1000 8'-4.5" 6840
200
0
0
3
196 140 0.72 16.7 4.90 0.57 21.0 6.16 248 259 300 400
549 572 600 1000 8'-4.5" 6840
210
1
1
2
214 154 0.72 16.7 4.90 0.57 21.1 6.17 272 282 300 450
601 623 700 1000 10'-10" 8548
220
1
0
3
228 163 0.72 16.7 4.90 0.57 21.1 6.20 290 300 350 450
641 664 700 1000 10'-10" 8665
230
1
0
3
228 163 0.72 16.7 4.90 0.57 21.1 6.20 290 300 350 450
641 664 700 1000 10'-10" 8665
240
0
1
3
247 177 0.72 16.7 4.90 0.57 21.0 6.17 313 323 350 500
692 715 800 1200 11'-2" 9003
250
0
1
3
247 177 0.72 16.7 4.90 0.57 21.0 6.17 313 323 350 500
692 715 800 1200 11'-2" 9003
260
0
0
4
261 187 0.72 16.7 4.90 0.57 21.1 6.19 331 342 350 500
733 755 800 1200 11'-2" 9120
270
1
2
2
265 190 0.72 16.7 4.90 0.57 21.0 6.14 336 346 350 600
743 766 800 1200 13'-7.5" 10711
280
1
1
3
279 200 0.72 16.7 4.90 0.57 21.2 6.20 354 365 400 600
784 807 1000 1200 13'-7.5" 10828
290
1
0
4
293 210 0.72 16.7 4.90 0.57 21.2 6.22 373 383 400 600 N/A N/A N/A N/A 13'-7.5" 10945
300
0
2
3
299 214 0.72 16.7 4.90 0.57 21.1 6.18 377 388 400 600 N/A N/A N/A N/A 13'-11.5" 11166
310
0
1
4
312 224 0.72 16.7 4.90 0.57 21.2 6.20 396 406 450 600 N/A N/A N/A N/A 13'-11.5" 11283
320
0
0
5
326 234 0.72 16.7 4.90 0.57 21.2 6.22 414 424 450 700 N/A N/A N/A N/A 13'-11.5" 11400
330
0
0
5
326 234 0.72 16.7 4.90 0.57 21.2 6.22 414 424 450 700 N/A N/A N/A N/A 13'-11.5" 11400
