CHIEF YAMF1 - Manual (Page 3)

Installation Instructions YAMF1
3
LEGEND
TOOLS REQUIRED FOR INSTALLATION
PARTS
Tighten Fastener
Apretar elemento de fijación
Befestigungsteil festziehen
Apertar fixador
Serrare il fissaggio
Bevestiging vastdraaien
Serrez les fixations
Loosen Fastener
Aflojar elemento de fijación
Befestigungsteil lösen
Desapertar fixador
Allentare il fissaggio
Bevestiging losdraaien
Desserrez les fixations
Open-Ended Wrench
Llave de boca
Gabelschlüssel
Chave de bocas
Chiave a punte aperte
Steeksleutel
Clй а fourche
Phillips Screwdriver
Destornillador Phillips
Kreuzschlitzschraubendreher
Chave de fendas Phillips
Cacciavite a stella
Kruiskopschroevendraaier
Tournevis à pointe cruciforme
M2.5 (included)
3/32" (included)
3/16" (included)
A (1)
[F1 mount arm with
head assembly]
B (1)
[F1 monitor mount]
C (1)
[F1 monitor
mount pin]
D (1)
E (2)
.51x.32x.875
F (4)
1/4-20 x 2-1/2" G (1)
5/16-18 x 5-1/2"
H (1)
[Snap bushing]
J (6)
1/4"
K (1)
5/16"
L (4)
1/4"
M (1)
5/16"
N (1)
10-32 x 3/8"
PA (4)
M4 x 12mm PB (4)
M4 x 20mm PC (4)
M4 x 30mm
PD (4)
.500 x .194 x .750
PE (4) .500 x .194 x .375
Q (1)
[Cable cover] R (2)
8-32 x 3/8"
S (1)
M2.5 T (1)
3/32" U (1)
3/16"
P (1) Hardware Kit
.640x.845x.094
