CHIEF NAWS1 - Manual (Page 3)

Installation Instructions NAWS1
3
LEGEND
TOOLS AND HARDWARE
PARTS FOR INSTALLATION
Tighten Fastener
Apretar elemento de fijación
Befestigungsteil festziehen
Apertar fixador
Serrare il fissaggio
Bevestiging vastdraaien
Serrez les fixations
Loosen Fastener
Aflojar elemento de fijación
Befestigungsteil lösen
Desapertar fixador
Allentare il fissaggio
Bevestiging losdraaien
Desserrez les fixations
Pencil Mark
Marcar con lápiz
Stiftmarkierung
Marcar com lápis
Segno a matita
Potloodmerkteken
Marquage au crayon
Drill Hole
Perforar
Bohrloch
Fazer furo
Praticare un foro
Gat boren
Percez un trou
7/32" (5.5mm) - wood
5/16" (7.9mm) - concrete
1/2"
Hardware required, not provided:
4 - 5/16-18 x 2-1/2" lag bolts
4 - 5/16" flat washers
4 - 5/16" toggler (for concrete install)
A (1)
[NAWS1]
