CHIEF PSBU - Manual (Page 4)

PSBU Installation Instructions
4
TOOLS REQUIRED FOR INSTALLATION
PARTS
1/8”
(included)
N (8)
T (2)
J (8)
P (8)
I (8)
.750x.323x.250
C (6)
G (8)
F (8)
S (4)
E (8)
D (6)
A (8)
U (2)
K (8)
M (8)
H (8)
L (8)
Q (8)
R (8)
V (1)
1/8”
Hardware Kit
Bag A Bag B Bag C
Bag D Bag E Bag F
Bag G Bag H Bag I
Bag J Bag K Bag L
Bag M Bag N Bag O
Bag P
B (6)
M8 x 16mm
#10-24 x 1/2"
M8 x 20mm
M8 x 35mm
M6 x 16mm M6 x 20mm
M6 x 35mm
M5 x 16mm
M5 x 25mm
M5 x 40mm
M4 x 16mm
M4 x 25mm
M4 x 40mm
O (8)
20mm
#10 .318x.078
1/4"
No bag label
M8 x 60mm
[Vertical bracket]
[Horizontal bracket]
Bag Q
