CHIEF PAC501 User Manual
Page 7
Installation Instructions
PAC501
7
DANGER:
IMPROPER WIRING CAN LEAD TO DEATH
OR SEVERE PERSONAL INJURY! Grounding must be
installed by qualified personnel using a UL Recognized No.
12AWG Green and Yellow grounding wire connected to
grounding lug on mount.
Figure 6
Installing Arm Kit
Install arm kit following instructions included with the kit.
Grounding Lug Locations
