Dimensions legend – CHIEF FCAC User Manual
Page 3
Installation Instructions
FCAC
3
DIMENSIONS
LEGEND
0.28
7.1
A
SHOWN WITH LCM2X1U
DETAIL A
SCALE 1 : 6
B
SHOWN WITH LCM2X1U
DETAIL B
SCALE 1 : 8
DIMENSIONS: INCHES
[MILLIMETERS]
Tighten Fastener
Apretar elemento de fijación
Befestigungsteil festziehen
Apertar fixador
Serrare il fissaggio
Bevestiging vastdraaien
Serrez les fixations
Loosen Fastener
Aflojar elemento de fijación
Befestigungsteil lösen
Desapertar fixador
Allentare il fissaggio
Bevestiging losdraaien
Desserrez les fixations
Phillips Screwdriver
Destornillador Phillips
Kreuzschlitzschraubendreher
Chave de fendas Phillips
Cacciavite a stella
Kruiskopschroevendraaier
Tournevis à pointe cruciforme
Hex-Head Wrench
Llave de cabeza hexagonal
Sechskantschlüssel
Chave de cabeça sextavada
Chiave esagonale
Zeskantsleutel
Clй а tête hexagonale
