Installation Instructions Model: KSA-1014
3
TOOLS REQUIRED FOR INSTALLATION
• Phillips Screwdriver
• 5/32" Hex Wrench
Other tools may be required depending on your method
of installation.
PARTS
After unpacking carton, inspect and verify contents
(See Table 1 and Figure 1). If any listed parts are
missing or damaged, contact Chief Customer Service at
1-800-582-6480.
Table 1: Parts
Item Description Qty
10 Centris Head Assembly 1
20 WASHER, Nylon 1
30 PIN, Pivot 1
40 SCREW, Button Head Cap, 5/16-18 x 4" 1
50* SCREW, Button Head Cap, 5/16-18 x 4 1/2" 1
60 Nut, NYLOCK, 5/15-18 1
70 SPACER 2
80 WASHER, UHMW 1
90 SCREW, Phillips head machine, M4 x 12mm 4
100 SCREW, Phillips head machine, M4 x 20mm 4
110 SCREW, Phillips head machine, M4 x 30mm 4
120 SPACER, Nylon, 1/2 x .194 x 3/8" 4
130 SPACER, Nylon, 1/2 x .194 x 3/4" 4
* Used when installing onan adjustable arm mount.
Figure 1: PARTS
10
20
30
40
50
60
70
80
90
100 110 120 130
