Installation instructions kfa series 3 – CHIEF KFA320 Series User Manual
Page 3
Installation Instructions
KFA SERIES
3
KFA-220 DIMENSIONS
KFA-225 DIMENSIONS
23.83
13.68
5.68
CLAMP FOR ATTACHING
TO PF AND MF SERIES
CARTS AND STANDS
1.96
4.50
IF SAME SIZE DISPLAY IS USED FOR BOTH,
MAXIMUM SCREEN WIDTH OF 22.7".
30.51
774.8
17.24
437.8
6.68
CLAMP FOR ATTACHING
TO PF AND MF SERIES
CARTS AND STANDS
1.96
49.8
4.50
114.3
IF SAME SIZE DISPLAY IS USED FOR BOTH,
MAXIMUM SCREEN WIDTH OF 30.0".
