Installation Instructions XVAU
5
TOOLS REQUIRED FOR INSTALLATION
PARTS
#2
M5 (included)
3/8”
1/2”
B (2)
[Interface upright]
E (1)
[Cart Assembly - shown
A (4)
[Upright cover]
PA (8)
M4x16mm
PB (6)
M4x20mm
PC (6)
M4x25mm
PD (6)
M5x16mm
PE (6)
M5x20mm
PF (6)
M5x25mm
PG (6)
M6x16mm
P (1)
[Hardware bag]
PH (6)
M6x25mm
PI (6)
M8x20mm
PJ (6)
M8x30mm
PK (4)
M8x50mm
PL (8)
1/4”
PM (8)
1/2”
PN (8)
[universal]
PP (1)
M5
F (10)
[FCA clip]
G (10)
[Cable tie]
C (4)
(Cable hook) D (4)
1/4-20 x 1/2”
Camera mount
H (1)
[Camera shelf]
J (1)
[Retaining bracket]
N (1)
[Upright]
K (4)
#10-24
L (1)
1/4-20 x 3/8”
M (3)
1/4-20 x 1/2”
on packaging pallet]
