XSM/XTM Series Installation Instructions
5
TOOLS REQUIRED FOR INSTALLATION
PARTS
7/32" (5.5mm) Wood Stud
#2
5/16" (7.9mm) Concrete
Custom
XSMXXXX /
XTMXXXX
Hardware
[Included with
XSMXXXX / XTMXXXX
Models Only]
JA (6)
M5
M (1)
R (1)
T (1)
N (1)
Q (4)
[A-K used on XSMU/XTMU Models Only]
A (6)
M6x16mm
B (6)
M6x25mm
C (6)
M8x20mm
D (6)
M8x30mm E (4)
M8x50mm
F (6)
M10x40mm
G (6)
M10x50mm
H (6)
I (6)
M6 M8
JB (6)
1.00x.400x.75"
.750x.323x.250"
KA (1) KB (1)
M6
(XTM Only)
S (1)
LA (4)
5/16" LB (4)
5/16"
LC (4)
5/16" x 2-1/2"
U (1)
(XSM Only)
(XTM Only)
P (1)
3/16" - 12"
