CHIEF XTM Series - Manual (Page 3)

Installation Instructions XSM/XTM Series
3
DIMENSIONS
1.75 44.5
1.00 25.4
.33 8.3
15.10 383.4
2.92 74.1 .96 24.4
48.54 1233
2.00 50.8
MINIMUM UPRIGHT SPACING 24"
RAILS CAN BE SLID LEFT
OR RIGHT FOR OFFSET
27.00 685.8
1.00 25.4
16.52 419.6
12°
1.92 48.7
MIN.
DEPTH
27.00 685.8
.51 12.9
.40 10.2
0
.59 15
.59 15
2.95 75
5.31
NOTES:
MAX MOUNTING PATTERN IS 44.7" (1135.4 mm) WITHOUT REVERSING UPRIGHTS. 1.
MAX MOUNTING PATTERN IS 49.2" (1249.7 mm) WITH REVERSING UPRIGHTS. 2.
FOR RECESSED APPLICATIONS, MINIMUM VERTICAL LIFT FOR HOOK ENGAGEMENT IS .41"[10.4mm].
MOUNT IS 1.92"[48.7mm] DEEP WHEN FLAT TO WALL.
XTM
DIMENSIONS: [MILLIMETERS]
INCHES
1.00
25.4
.96
24.3
.33
8.3
15.10
383.4
2.91
73.9
1.75
44.5
48.56
1233.4
1.54
39.1
RAILS CAN BE SLID LEFT
OR RIGHT FOR OFFSET
MINIMUM UPRIGHT SPACING 24"
1.00
25.4
16.52
419.6 2.23
56.6
27.00
685.8
.81
20.6
1.77
45
1.18
30
0
.59
15
2.95
75
5.31
NOTES:
MAX MOUNTING PATTERN IS 46" (1168.4 mm) WITHOUT REVERSING UPRIGHTS. 1.
MAX MOUNTING PATTERN IS 48.4" (1229.4 mm) WITH REVERSED UPRIGHTS. 2.
FOR RECESSED APPLICATIONS, MINIMUM VERTICAL LIFT FOR HOOK ENGAGEMENT IS .56"[14.2]. 3.
MOUNT IS 2.23"[56.6mm] DEEP WHEN FLAT TO WALL.
XSM
DIMENSIONS: [MILLIMETERS]
INCHES
