CHIEF STLU - Manual (Page 5)

Installation Instructions STLU
5
TOOLS REQUIRED FOR INSTALLATION
PARTS
7/16" (11.1mm)
3/16" (security)(included)
5/32" (security)(included)
5/16"
B (1)
D (2)
[table stand interface]
[vertical interface bracket]
A (1)
[clamping plate]
F (1)
[cable port cover]
G (3)
1/4-20 x 2 1/2"
H (4)
1/4-20 x 1/2"
J (4)
1/4-20 x 1/2"
K (1)
#10-24 x 1/2"
L (3)
3/16"
Hardware Bag
C (1)
[table stand]
(security) (security)
N (4)
M4x12mm
P (4)
M4x16mm
Q (4)
M5x16mm
R (4)
M6 x 16mm
S (4)
M8x16mm
T (4)
#10
U (8)
1/4"
V (1)
3/16"
W (1)
5/32"
(security) (security) (security) (security) (security) (security) (security)
E (2)
[interface clamp bracket] M (1)
#10-24 x 1/2"
