CEMB USA K22 (C) - Manual (Page 4)

I 0685 - 4
2 2a
GB
1.4 - Technical data
Weight (excluding adapter) ~ 70 kg
Single-phase power supply 115/230 V - 50/60 Hz AC
12-24 V DC (
use without motor )
Protection class IP 54
Max. power absorbed 800 W
Balancing speed < 80 min -1
Cycle time for average wheel (14 kg) 6-8 seconds
Max. resolution of measurement 1 gram
Position resolution ± 1.4 °
Average noise < 70dB (A)
Rim-machine distance 0 - 325 mm (with extension + 10)
Rim width setting range 1.5” - 20” or 40 - 510 mm
Diameter setting range 10” - 30” or 265 - 765 mm
2 - HANDLING AND LIFTING
NB: DO NOT LIFT THE WHEEL BALANCER USING OTHER GRIPS.
