I 0457 - 4
2 2a
GB
1.4 - Technical data
Single-phase power supply 115 / 230 V - 50/60 Hz
Protection class IP 54
Max. power absorbed 0,8 Kw
Balancing speed < 100 min -1
Cycle time for average wheel (14 kg) 6-8 seconds
Max. resolution of measurement 1 gram
Position resolution ± 1.4 °
Average noise < 70dB (A)
Rim-machine distance 0 - 252 mm
Rim width setting range 1.5” - 20” or 40 - 510 mm
Diameter setting range 10” - 30” or 265 - 765 mm
2 - Handling and lifting
Note: DO NOT LIFT THE WHEEL BALANCER USING OTHER GRIPS.
3 - Startup
3.1 - Anchoring
The machine can operate on any fl at non resilient fl oor.
Make sure that the machine rests solely on the three support points provided (Fig.2a).
It is advisable to secure the system to the ground using the specifi c feet (Fig. 2a). if the machine is
continually used with wheels weighing over 35 kg.
3.2 - Electrical connection
The machine is supplied with a single-phase mains cable plus earth (ground).
The power supply voltage (and mains frequency) is indicated on the machine identifi cation plate and cannot be
changed. Connection to the mains must always be made by expert personnel.
The machine must not be set up without proper earthing.
Connection to the mains should be through a slow acting safety switch rated at 3 A (230V) or 8 A(115 V).
See enclosed diagram.
