5.5.1 - INDICATION OF EXACT CORRECTION WEIGHT POSITION

It is possible use this function in the event of correction of the external side using an adhesive weight

placed inside the rim.

This function allows cancelling approximations in the mounting of counterweights with consequent

reduction of the residual unbalance.

- Press button

from the Measurements screen.

- Pull out the rim distance+diameter gauge

in position A, figure 8. Approach of the weight to the

correction position is indicated by a moving coloured arrow [ ].

- When a fixed arrow [ ] is reached, rotate the wheel to correction position (FI or FE) and apply the

counterweight by turning the tip of the gauge towards the outside, into the position

in which the pin-

cers touches the wheel. Compensation is made for the fact that the weight application position is no

longer at 12 o’clock (fig. 11).

When the acoustic signal is enabled (see

ACOUSTIC SIGNAL

), the reaching of a fixed arrow [ ] is

accompanied by a “beep”.

Fig. 11
