9. Connect the 9-pin plug connectors. Attach the lower switch housing to
the upper switch housing with the three thumb screws.
10. Attach the lower rain shield to the upper rain shield with four screws.
Securely tighten all four screws.
11. Attach the wire cage to the lower rain shield with four screws. Securely
tighen all four screws.
12. Install a 75 W Max A-19 bulb.
13. Raise the glass globe and align the indents in the glass globe with the tabs
on the fitter. Twist the glass globe clockwise to secure.
14. Restore power to the ceiling fan.
95420.eps
Step 9
95420b.eps
Steps 10
95420_inst.eps
Steps 12-13
95420_inst2.eps
Step 11 Lower Rain
Shield
Wire Cage
Glass
Globe
