Hunter 28568 Swirled Marble Dual Use Bowl Light Kit User Manual
Page 5
5
43550-01 • 06/10/10 • Hunter Fan Company
9 . Install the included CFL light bulbs into the lamp sockets .
10 . Remove the lower chain extension from the light fixture by unhooking it from the breakaway connector .
Leave the breakaway connector in place on the upper chain .
11 . Thread the light pull chain through the hole in the center of the glass bowl . Place the glass bowl on the
threaded rod until flush against the metal disc .
12 . Place a cover plate (with no side hole) up against the glass bowl . Thread the light pull chain through the
center opening of the cover plate .
13 . Thread the light pull chain through the finial and screw the finial onto the threaded rod until tight .
14 . The installation is complete and you can restore power to the light fixture .
1 • Installing the Light Kit on the Ceiling (contintued)
Cover
Plate
Light Pull
Chain
Finial
Steps 11-14
