Hunter 99164, 99165, 99166 Traditional Globe Light Kit - Manual (Page 6)

MA022-01 • 03/07/14
1.888.830.1326
6
TYPE-B ASSEMBLY INSTRUCTIONS
Using the single pin connectors,
connect the black or blue wire from the
fan to the black wire from the light kit.
Connect the white wire from the fan to
the white wire from the light kit.
Do not allow the light kit to hang
only by the wire connections!
If your fan does not have pin connectors on
the wires coming from the switch housing,
install the wiring harness provided. Using
the provided wire connectors connect the
white wire from the fan to the white wire
from the wire harness and connect the
black or blue wire from the fan to the black
wire from the wire harness.
Wire
Connector
Switch
Housing
Install a bulb into each of the sockets.
When necessary, replace with bulbs of
the same wattage.
Bulb
Mounting
Screw
Lift the light kit up to meet the lower
switch housing. Using the mounting
screws found in the hardware bag,
install the light kit to the adapter.
2 1
4 3
