WebSTAR DPR2320 and EPR2320 Gateway Cable Modems User’s Guide
22
How Do I Connect Ethernet Network Devices?
Connecting Ethernet Devices
You must connect your Ethernet devices for use with the gateway cable modem.
Professional installation may be available. Contact your local cable service
provider for further assistance.
The following diagram illustrates one of the various Ethernet network connection
options that are available to you.
POWER
ANTENNA
12 VDC
RESET
ETHERNET
CABLE
USB
Power
Supply
Cable-Ready TV,
VCR, or Set-Top
Converter
PC
USB Cable
RF
Cable
RF
Cables
Cable
Splitter
T10949
P ower S upply
BYPASS
VOLñ VOL+ CH+
CHñ MENU GUIDE INFO A/B POWER
Ethernet
Hub
PC
PC
Wireless
Laptop PC
Wireless
Laptop
