WebSTAR DPR2320 and EPR2320 Gateway Cable Modems User’s Guide
76
Front Panel Status Indicator Functions
Initial Power Up, Calibration, and Registration
The following chart illustrates the sequence of steps and the corresponding
appearance of the cable modem front panel status indicators during power up,
calibration, and registration on the network. Use this chart to troubleshoot the
power up, calibration, and registration process of your cable modem.
After the cable modem completes step 7 (Registration Completed), the
modem proceeds immediately to step 8 (Normal Operations).
Front Panel LED Status Indicators During Initial Power Up, Calibration, and Registration
Front Panel LED Status Indicators During Initial Power Up, Calibration, and Registration
Step
1
POWER
Front Panel
Indicator
2
3
1
ON
Self
Test
7
ON
Registration
Completed
2
ON
Downstream
Scan
3
ON
Downstream
Signal Lock
4
ON
Ranging
5
ON
Requesting
IP Address
5
PC
ON
ON
ON
or
BLINKING
ON
or
BLINKING
ON
or
BLINKING
ON
or
BLINKING
ON
or
BLINKING
6
ON
Registering
6 WIRELESS
ON
ON
ON
or
BLINKING
ON
or
BLINKING
ON
or
BLINKING
ON
or
BLINKING
ON
or
BLINKING
4
CABLE
ON
ON
SLOW
BLINKING
1 blink
MOMENTARY
ON
OFF
BLINKING
2 blinks
BLINKING
4 blinks
RECEIVE
ON
ON
OFF
OCCASIONAL
BLINKING
OCCASIONAL
BLINKING
OCCASIONAL
BLINKING
OCCASIONAL
BLINKING
SEND
ON
ON
OFF
OFF
OCCASIONAL
BLINKING
OCCASIONAL
BLINKING
OCCASIONAL
BLINKING
T10711
Normal Operations
The following chart illustrates the appearance of the cable modem front panel
LED status indicators during normal operations.
Front Panel LED Status Indicators During Normal Operations
Front Panel LED Status Indicators During Normal Operations
Step
1
POWER
Front Panel
Indicator
ON
Normal Operations
(Bold denotes normal)
5
PC
2
RECEIVE
4
CABLE
ON - When a single device is connected to either the Ethernet or USB port and no data is being
sent to or from the modem.
BLINKS - LED blinks when only one Ethernet or USB device is connected and
data is being transferrd between the consumer premise equipment (CPE) and the cable modem.
OFF - When no devices are connected to either the Ethernet or USB ports.
Note: With both Ethernet and USB devices connected to the modem at the same time, when data is being
transferred through only one of the devices (Ethernet or USB), the indicator will illuminate continuously.
Whenever data is being sent through both data ports (Ethernet and USB) simultaneously, the indicator
will blink as described above.
6 WIRELESS ON - When the wireless access point is operational.
BLINKS - To indicate data is being transmitted through the wireless access point.
OFF - When the user disables the wireless access point.
BLINKS - To indicate data is being transferred between the modem and the network.
3
SEND
BLINKS - To indicate data is being transferred between the modem and the network.
ON
8
T10712
