WebSTAR DPR2320 and EPR2320 Gateway Cable Modems User’s Guide
30
How Do I Install Wireless Network Devices?
Installing Wireless Network Devices
You must install wireless network devices for use with your gateway cable
modem. Professional installation may be available. Contact your local cable
service provider for further assistance.
The following diagram illustrates one of the various wireless network connection
options that are available to you.
POWER
ANTENNA
12 VDC
RESET
ETHERNET
CABLE
USB
Power
Supply
Cable-Ready TV,
VCR, or Set-Top
Converter
PC
USB Cable
RF
Cable
RF
Cables
Cable
Splitter
T10949
P ower S upply
BYPASS
VOLñ VOL+ CH+
CHñ MENU GUIDE INFO A/B POWER
Ethernet
Hub
PC
PC
Wireless
Laptop PC
Wireless
Laptop
