6 • Installing the Canopy
6-1. Partially install two canopy screws (about 2 full turns) in
the hanger bracket.
6-2. Raise the canopy over the hanger bracket. Align partially
installed screws with key slots in canopy.
6-3. Twist canopy counterclockwise to secure.
6-4. Install third canopy screw in round hole on canopy.
Securely tighten all three screws.
Canopy
Screw
Canopy
Screw
Canopy
Step 6-1
Step 6-3
