Table 1B
Gas Pack Specifications
1) United States Installation
2) Specification subject to change without notice. See sales specification sheets for certain BTUH capacities.
3) This PGC series complies with requirements embodied in the American National Standard ANSI-Z21.47 Central Furnaces.
4) Filters are not supplied with units, but filters must be installed in the unit filter rack or in the return air system.
** While the above data is presented as a guide, it is important to electrically connect the unit and properly size overcurrent protection and wires in accordance with the
National Electrical Code and all existing local codes.
Operating tolerance: Minus 5% on 208 VAC, Plus 10% on 208 VAC and 230 VAC, Minus 10% on 230 VAC
MODEL PGC42B0902A PGC42B1152A PGC48B0902A PGC48B1152A PGC60B0902A PGC60B1352A
Cooling Capacity Btuh 42,000 42,000 48,000 48,000 60,000 60,000
SEER 12.20 12.20 12.00 12.00 12.00 12.00
Heating
Input Btuh 90,000 115,000 90,000 115,000 90,000 135,000
Output Btuh 72,000 89,000 72,000 89,000 72,000 108,000
AFUE 81.4 79.9 81.4 79.9 81.4 80.5
Tem perature Rise °F 25-55 40-70 25-55 40-70 25-55 40-70
Num ber of Burners 4 5 4 5 5 6
Compressor
R.L. Amps 22 22 21.8 21.8 28.8 28.8
L.R. Amps 107 107 105 105 169 169
Condenser Coil
Face Area (sq. ft.) 17.2 17.2 17.2 17.2 17.2 17.2
Row s Deep 2 2 2 2 2 2
Fins/Inch 13 13 17 17 17 17
Condenser Fan
Diameter (in.) 24 24 24 24 24 24
CFM 3500 3500 3700 3700 4700 4700
Condenser Fan Motor
Horsepow er 1/4 1/4 1/2 1/2 1/3 1/3
R.L. Amps 1.5 1.5 1.5 1.5 2.5 2.5
L.R. Amps 3.4 3.4 3.6 3.6 6.4 6.4
Blow er Motor
Horsepow er 3/4 3/4 3/4 3/4 1 1
R.L. Amps 5 5 5 5 7 7
L.R. Amps
Blow er Wheel Dia. x Width (in.) 10x10 10x10 10x10 10x10 11x8 11x8
Rated CFM, Cooling 1450 1450 1700 1700 1750 1750
Max. External 0.8" w c 0.8" w c 0.8" w c 0.8" w c 0.8" w c 0.8" w c
Combustion Blow er
Diameter x Width (in.) 4 x 1.25 4 x 1.25 4 x 1.25 4 x 1.25 4 x 1.25 4 x 1.25
No. 1 1 1 1 1 1
Condenser Blow er Motor
H.P. 0.03125 0.03125 0.03125 0.03125 0.03125 0.03125
F.L. Am ps. 0.5 0.5 0.5 0.5 0.5 0.5
Press. Sw itch Setting (" W.C.) -0.65 -0.65 -0.65 -0.65 -0.65 -0.65
Ignition - Lockout Timing (sec.) 4 4 4 4 4 4
Flame Sense Current (m icroam ps)
Minim um 1 1 1 1 1 1
Maximum 6 6 6 6 6 6
Evaporator Coil
Face Area (Sq. Ft.) 5.7 5.7 5.7 5.7 5.7 5.7
Row s Deep 2 2 3 3 3 3
Fins/Inch 15 15 15 15 15 15
External Filter Size (Sq. Ft.) 5.3 5.3 5.3 5.3 5.3 5.3
Drain Line Size (in.) 3/4 3/4 3/4 3/4 3/4 3/4
Expansion Device (Cooling) Capillary Capillary TEV TEV TEV TEV
Refrigerant Charge Refer to unit name plate for correct charge
Pow er Supply** 208/230-60-1 208/230-60-1 208/230-60-1 208/230-60-1 208/230-60-1 208/230-60-1
Min. Circuit Ampacity 34 34 39.5 39.5 49.7 49.7
Max. Overcurrent Device 50 50 50 50 70 70
Electrical Entrance Size
Pow er Supply 1 1/4", 1 1/2", 2" 1 1/4", 1 1/2", 2" 1 1/4", 1 1/2", 2" 1 1/4", 1 1/2", 2" 1 1/4", 1 1/2", 2" 1 1/4", 1 1/2", 2"
Low Voltage 7/8" 7/8" 7/8" 7/8" 7/8" 7/8"
Approx. Shipping Weight (lbs) 521 527 526 526 531 531
Protected by redundant electronic control circuts
