14

Figure 8

Typical Electrical Wiring

Typical Wiring

(Ground Level)

Disconnect Switch

High Voltage Source

High Voltage
Entrance

Low Voltage
Entrance

Typical Wiring

(Rooftop)

Disconnect Switch

High Voltage Source
High Voltage
Entrance

Low Voltage

Entrance

Junction

Box

Rooftop

Curb
