13
Common Roll Tarp Parts
Description Part No. Qty.
Nylon Strip JM0001471 1
Stop Bracket JM0001494 3
Prop Up Bar JM0000917 2
Plastic Standoffs JM0001496 2
J-Bolt-Small JM0001519 1
Hanger Bracket JM0000815 1
Hanger Bracket Hook JM0001497 1
1/4” Flange Nuts JM0001499 52*
1/4” x 1/2” JM0001481 27
1/4”x 5/8” JM0001479 5
1/4” Locknut JM0001505 1
1/4” x 2 1/2” JM0001506 1
1/4” x 3/4” JM0001507 20*
3/8” Flange Nuts JM0001508 4
3/8” x 1” Flange JM0001509 4
3/8” x 2” JM0001510 5
3/8” Locknut JM0001512 6
1/2” Locknut JM0001511 1
1/2” x 1 1/4” JM0001513 1
1/8” Cable Clamp JM0001514 1
3/16” Cable Clamp JM0001515 1
Universal Joint JM0001517 1
1/4” Drive Rivet JM0001518 10
1/4” x 1 1/2” Self Tapping JM0001571 4
Model Specific Roll Tarp Parts
Description Part No. Qty.
250 Roll Tarp
Tarp Crank Handle Small JM0000889 1
1” x 1” 14 ga Square Tubing x 120” JM0001531 1
1.25” x 1.25” Roll Tube 126” JM0001537 1
Drip Edge 120” JM0001549 1
Back Endcap Arch 84” JM0001546 1
Front Endcap Arch 84” JM0001543 1
Back End Plate 84” JM0001549 1
Front End Plate 84” JM0001545 1
250 Tarp Bows JM0001583 3
3/16” Diameter Ridge Cable 120” JM0001525 1
250 Canvas Tarp JM0001589 1
385 Roll Tarp
Tarp Crank Handle Small JM0000889 1
1” x 1” 14 ga Square Tubing x 148” JM0001534 1
1.25” x 1.25” Roll Tube 154” JM0001538 1
Drip Edge 148” JM0001552 1
Back Endcap Arch 94” JM0001554 1
Front Endcap Arch 94” JM0001550 1
Back End Plate 94” JM0001555 1
Front End Plate 94” JM0001551 1
385 Tarp Bows JM0001584 3
3/16” Diameter Ridge Cable 148” JM0001524 1
385 Canvas Tarp JM0001588 1
440/540 Roll Tarp
Tarp Crank Handle Small JM0000889 1
1” x 1” 14 ga Square Tubing x 180” JM0001535 1
1.25” x 1.25” Roll Tube 186” JM0001539 1
Drip Edge 180” JM0001567 1
Back Endcap Arch 100” JM0001565 1
Front Endcap Arch 100” JM0001563 1
Back End Plate 100” JM0001566 1
Front End Plate 100” JM0001564 1
440 Tarp Bows JM0021006 3
540 Tarp Bows JM0000812 3
3/16” Diameter Ridge Cable 180” JM0001526 1
1/4” x 3/4” Self Tapping JM0001570 4
440/540 Canvas Tarp JM0001587 1
680/760 Roll Tarp
Tarp Crank Handle Medium JM0001541 1
1” x 1” 14 ga Square Tubing x 198” JM0001536 1
1.25” x 1.25” Roll Tube 204” JM0001540 1
Drip Edge 198” JM0001576 1
Back Endcap Arch 114” JM0001574 1
Front Endcap Arch 114” JM0001572 1
Back End Plate 114” JM0001575 1
Front End Plate 114” JM0001573 1
680 Tarp Bows JM0021010 4
760 Tarp Bows JM0001585 4
3/16” Diameter Ridge Cable 198” JM0001527 1
1/4” x 3/4” Self Tapping JM0001570 4
680/760 Canvas Tarp JM0001586 1
ROLL TARP PART NUMBERS
*Add 4 to quanity for every tarp bow
added after 3 total.
