4 connectors – Asus T3-M2NC51PV User Manual
Page 51

4-5
ASUS T3-M2NC51PV
4.4
Connectors
This section describes and illustrates the connectors on the motherboard.
1. CPU fan connector (4-pin CPU_FAN)
The fan connector supports the proprietary CPU fan. Connect the fan
cable to the fan connector on the motherboard, making sure that the
black wire of the cable matches the ground pin of the connector.
Do not forget to connect the fan cables to the fan connectors.
Insufficient air flow within the system may damage the motherboard
components. These are not jumpers! DO NOT place jumper caps on the
fan connectors!
R
M2N5-BN
M2N5-BN CPU Fan Connector
CPU_FAN
GND
CPU F
AN PWR
CPU F
AN IN
CPU F
AN PWM
