Page 16

1-6
Chapter 1: System introduction
1. 5.25-inch optical drive
2. Hard disk drive metal tray
3. ASUS motherboard
4. AMD
®
AM2 socket
5. DIMM sockets
6. Serial ATA connectors
7. PCI Express™ x16 slot
8. PCI slot
9. Expansion card slots
10. Power supply unit
1.5
Internal components
The illustration below is the internal view of the system when you remove
the top cover and the power supply unit. The installed components are
labeled for your reference. Proceed to Chapter 2 for instructions on
installing additional system components.
4
5
10
6
9
7
8
3
1
2
