NEULOG PULSE SENSOR GUIDE
Heart Rate and Physical Activity -
Technical background:
The philosophy behind NeuLog’s plug and play technology is based on each sensor’s
ability to store its own data due to an internal flash memory chip and micro-controller
in each plastic NeuLog body. This technology allows the sensor to collect and then
store the digital data in the correct scientific units (
o
C,
o
F, Lux, %, ppm, for example).
The sensor is pre-calibrated at the factory. The built-in software in the logger can be
upgraded for free at any time using the provided firmware update.
The pulse sensor’s probe consists of a fingertip/earlobe clip which houses an infrared
light source and an infrared light detector on opposite sides. Blood absorbs infrared
light much more effectively than tissue. Therefore the amount of blood (volume) is
inversely proportional to the amount of light measured by the light detector. This
relationship easily allows for the calculation of blood volume. Pulse is calculated from
the blood volume wave signal using the frequency.
Maintenance and storage:
Never submerge the NeuLog plastic body in any liquid.
Do not allow liquid into the heart rate and pulse sensor’s body.
After use, gently wipe away any foreign material from the heart rate and
pulse sensor.
Store in a box at room temperature out of direct sunlight.
Warranty:
We promise to deliver our sensor free of defects in materials and workmanship for a
period of 3 years from the date of purchase. Our warranty does not cover damage of
the product caused by improper use, abuse, or incorrect storage. Sensors with a shelf
life such as ion selective proves have a warranty of 1 year. Should you need to act
upon the warranty please contact your distributor. Your sensor will be repaired or
replaced.
Thank you for using NeuLog!
Flexible, simple, fast, forward thinking.
W
A: 850 St Paul Street, Suite 15, Rochester, NY 14605
P: 1.866.553.8536
V04302013
