NEULOG PULSE SENSOR GUIDE
A USB to mini USB cable (which comes with the USB-200)
Procedure:
1.
Connect the heart rate and pulse sensor directly to the left side of a charged
BAT-200 module.
2.
When ready to collect data press the “Start/Stop” button on the heart rate
and pulse sensor, a red light will turn on for the duration of the experiment.
3.
To change the experiment settings first connect to your chosen device (PC,
Mac
, tablet, smart device) and select the “Module setup” button. (For more
information on how to change the experiment settings view quick start
procedure section for your chosen device in this document.)
4.
After the experiment has concluded (when the
“Start/Stop” button is pressed
again or the data collection period ends) connect the sensor to your chosen
device. (full instructions in each device’s quick start procedure section)
5.
Open NeuLog software.
6.
Click the “Off-line experiment” button.
7.
Click the “Load data from sensors” button.
8.
Select which experimental data to upload. (5 experimental runs can be
stored at one time on the NUL-208 heart rate and pulse sensor)
Restoring sensor’s factory default settings:
Procedure:
1.
Connect the USB-200 to a PC, Mac, tablet, or smart device.
2.
Connect the heart rate and pulse sensor to a USB-200 module (they directly
plug together). Please note there is no calibration required for this sensor.
3.
Open the NeuLog software.
4.
Click the “Tools” icon.
5.
Click “Restore sensor’s factory defaults” icon.
6.
If prompted to clear the graph, click either the “Off-line experiment” or “On-
line experiment” (whichever you are using).
7.
Click “Clear experiment results”.
8.
Resume from step 4.
Included with sensor:
NeuLog NUL-208 Heart Rate and Pulse Sensor Guide (this document).
Fingertip/earlobe clip with two internal plethysmograph based electrodes.
Sensor specifications
Beats per minute
Arbitrary analog
units (wave
function)
Range and
operation modes
30 to 240
0-1024 Analog
values
ADC resolution
10 bit
Accuracy
1
1
Resolution
2 BPM
1
Max sample rate
(S/sec)
100
10,000
Sensor features:
Fully digital data.
Rugged plastic ergonomic case.
Push button switch for Start/Stop experiments in off line mode.
LED indicator of experiment status (blinks while collecting data).
Pre-calibrated sensing equipment.
Pulse sensing electrodes located in the probe clips which are attached
directly to the sensor’s plastic body.
Note: NeuLog products are intended for educational use.
Videos and experiment examples:
Videos, literature and other probes can be found at
www.NeuLog.com
Heart Rate and Coughing -
