Page 4
NEULOG PH SENSOR GUIDE
Restoring sensor’s factory default settings:
Procedure:
1.
Connect the USB-200 to a PC, Mac, tablet, or smart device.
2.
Connect the pH sensor to a USB-200 module (they directly plug together).
3.
Open the NeuLog software.
4.
Click the “Tools” icon.
5.
Click “Restore sensor‟s factory defaults” icon.
6.
If prompted to clear the graph, click either the “Off-line experiment” or “On-
line experiment” (whichever you are using).
7.
Click “Clear experiment results”.
8.
Resume from step 4.
Included with sensor:
Neulog pH Logger Sensor.
Neulog Electrode with Storage Solution container (attached to the sensor).
Neulog NUL-206 pH Sensor Guide (This Document).
Sensor specifications:
Range and operation modes
0 to 14 pH
ADC resolution
16 bit
Resolution
0.01 pH
Max sample rate (S/sec)
100
Electrode specifications:
Body diameter
12mm
Overall length
150mm
Cap
16mm OD ± 30mm Long
Construction
Epoxy body, round bulb ASG
VIII pH glass, sealed, gel-filled
single-junction reference with
fiber frit, Ag/AgCl wire, ATC
Range/output
0
– 14 pH
mV output with
isopotential
point at
0 ± mv at 25°C
Response time
98% of full response in 30
seconds at 25°C
Sensor features:
Fully digital data
Rugged plastic ergonomic case
Push button switch for Start/Stop experiments in off line mode
LED indicator of experiment status (blinks while collecting data)
Attached electrode cased in durable plastic for pH detection
Note: Neulog products are intended for educational use.
Videos and experiment examples:
Videos, literature and other probes can be found at
www.neulog.com
Acid Rain -
Properties of Sea water and Fresh Water -
