SUGGESTED INSTALLATION
11
Inlet
Optional Strainer
Flex Connector
Pressure Gauge with
Optional Diaphragm Seal
Air Supply
Filter Regulator
Pulsation Damper
Isolation Valve
Flex Connector
Pressure Gauge
with Optional
Diaphragm Seal
This illustration is a generic
representation of an air operated
double-diaphragm pump.
