Schreiber Chillers Excellon MM30AC User Manual
Page 19
30AC – 230/1
If this unit has special feature(s) installed, see appendix for part number(s).
Part Number
Description
Qty.
Refrigeration
R30
1/3-HP – (R134A CONDENSING UNIT)
1
R140-.3B Expansion
Valve
1
R146-.5
Refrigeration Sight Glass
1
R155
Refrigeration Drier – ¼”
1
R300
Cooling Coil For 30AC - Evaporator
1
R184
High Pressure Switch
1
R185
Low Pressure Switch
1
Electrical
E103-220
Contactors – 30 Amps – 240 COILS
1
E104
4 Point Terminal Block
1
E115 Grounding Screw
1
E121
ON/OFF Switch – 30 AC
1
E121-1
Contact Block – N/O 30AC ON/OFF Switch
1
E121-2
Nameplate – 30AC ON/OFF Switch
1
E109
Fuse Block
1
E 109-F10
10 amp fuse -600V – 10A
2
E136-30
Water Pressure Gauge – 2.5” – 0-160 PSI – Liquid Filled
1
E170
240V Relay
1
E170-1
Base For 240V Relay
1
E400
Temperature Control For Micro Max
1
Plumbing
P131
60 PSI Brass Pump
1
P131-M
1/3 HP 1PH Emerson Motor
1
P131-C
Clamp for Motor
1
P30
Stainless Steel Tank
1
P100
⅛” MNPT X ¼” Brass Hose Barb
1
P102
⅛” MNPT X ¼” Brass Hose Barb
1
P104
⅜” MNPT X ⅜” Brass Hose Barb
5
A06
⅜” Stainless Steel #6 Hose Clamp
5
A07
¼” Stainless Steel #4 Hose Clamp
2
F025306
⅜” Brass Drain Valve
1
BB-10-3/8CLR
⅜” Clear Filter Housing
1
BB-10-C-3/8
5 Micron Cartridge for ⅜” Housing
2
Cabinet
P149-WSGA
Water Sight Glass – Full Assembly
1
CA30-W
Cabinet – Unicream/Birch White
1
A01
Snap-In Flush Mount Recessed Door Handle
2
C101
2” X 15/16” Swivel Caster W/ Brake
4
