PARTS LIST
28
Hypertherm
301AC-A-200/3 (039099); 301AC-A-230/3 (039116)
If this unit has special feature(s) installed, see appendix for part number(s).
Part Number Description 220/3 Qty.
Refrigeration
R105 3 HP Compressor 9 1
R122 Condenser – Air Cooled 9 1
R131 Receiver 9 1
R140-3 Expansion Valve 9 1
R141-1 Expansion Valve Flange 9 1
R146-1 Refrigeration Sight Glass 9 1
R152 Drier 9 1
R166 Evaporator 9 1
R180 Suction Line Heat Exchanger 9 1
R182 High Pressure Switch 9 1
R183 Low Pressure Switch 9 1
Electrical 9
E101 Disconnect – 80 amp 9 1
E101-H Disconnect Handle Only 9 1
E101-S Disconnect Shaft Only 9 1
E103 Contactor – 30 amp 9 2
E104 Terminal Block 9 2
E106 Strain Relief Connector 9 1
E112 Transformer 220/3 9 1
E115 Ground Screw 9 1
E122 On/Off Switch 9 2
E124-3 Pilot Light Bulbs 24v 9 3
E126 Pilot Light Assembly (Green Lens) 9 2
E126-R Pilot Light Assembly (Red Lens) 9 1
E130 High Temperature Thermostat 9 1
E131 Adjustable Differential Thermostat 9 1
E134 Dial Thermometer – Discharge 9 1
E135 Dial Thermometer – Return 9 1
E136 Water Pressure Gauge 9 1
E136-PS Pressure Snubber for Water Pressure Gauge 9 1
E137 High Pressure Water Control 9 1
E145 Fan Motor 1/2 HP 1140 RPM 9 1
E148 Fan Blade – 18” 24 ° Pitch 9 1
E153-20B Fan Guard – Black 9 1
E155 Flasher Module 9 1
E166 Relay 9 2
E167 Relay Base 9 2
