50AC

FAN MOTORS

SPECIFICATIONS:

H.P. 1/4

VOLTAGE - 115/120/208/230 – 1 Phase

HZ - 60

RPM: 1725

OVERLOAD - Automatic, Internal

FRAME - LA56

MTG – Rigid Open Motor

CAT. NO.

LEESON #101708 - 230/1

ROTATION:

Motor runs clockwise (CW), from top view.

FAN BLADE:

14" x 16

5/8” Hub

SAFETY:

Avoid personal injury or equipment damage by disconnecting electrical power before
working on the motor. Make sure the power is off when checking each phase.

MAINTENANCE:

1. There are no lubrication points, therefore, no lubrication is necessary.
2. Make sure the blade runs in the correct rotation.
3. Clean the outside of the fan motor as necessary.
