PARTS LIST
1500AC/WC - 460/3 or 230/3 -
If this unit has special feature(s) installed, see appendix for part number(s).
Part Number Description 460/3 230/3 Qty.
Refrigeration
R109-01 Compressor – 230/3 – 7.5 HP 9 2
R110-01 Compressor – 460/3 – 7.5 HP 9 2
R125-A Condenser – Air Cooled 9 9 2
R125-W Condenser – Water Cooled 9 9 2
R170 Evaporator (All Copper) 9 9 2
R140-7 Expansion Valve – 7.5 HW 9 9 2
R141-7 Expansion Valve Flange 9 9 2
R146-15 Refrigeration Sight Glass 9 9 2
R153 Refrigeration Drier – 5/8” 9 9 2
R134 Receiver – 7.5 – 10 Ton 9 9 2
R194 Suction Accumulator 9 9 2
R181 Suction Line Heat Exchanger 9 9 2
R182 High Pressure Switch 9 9 2
R183 Low Pressure Switch 9 9 2
R192 Vibrator Eliminator – 1 3/8” 9 9 2
R137 7/8” Check Valve 9 9 2
R135-1 Rotalock Adapter 9 9 2
R136-2 Rotalock Valve 9 9 2
Electrical
E100 Disconnect 100 amp 9 9 1
E101-H Disconnect Handle Only 9 9 1
E101-S Disconnect Shaft Only 9 9 1
E115 Grounding Screw 9 9 1
E104 Terminal Block 9 9 1
E103 Contactors – 30 amps 9 9 4
E111 100 VA Transformer 9 9 1
E143-B 1 HP Fan Motor 1725 RPM 9 9 2
E149 Fan Blade 24” 9 9 2
E153-24 Fan Guard for 24” Blade 9 9 2
E124-3 Pilot Light Bulb 24V 9 9 1
E128A-2 Solid State Control Board w/ Low Level Cut-out &
Remote Alarm 9 9 1
E128P-D Discharge Probe Wire 9 9 14 ft
E128P-R Return Probe Wire 9 9 11 ft
E136 Discharge Pressure Gauge 9 9 1
E166 Relay 9 9 2
E167 Relay Base 9 9 2
E151 Fan Rain Shields 9 9 2
