FAN MOTORS

AIR COOLED

SPECIFICATIONS:

H.P. 1/2 – 2 each.

VOLTAGE - 460/200/230 PHASE 3

HZ-50-60

RPM 1140

OVERLOAD - Automatic, Internal

FRAME - LA56

MTG - Rigid, Open Motor

CAT. NO.

Leeson - 115726

ROTATION:

Motor runs clockwise (CW) looking from top of units..

FAN BLADE:

18" x 23

CW – 2 each.

SAFETY:

Avoid personal injury or equipment damage by disconnecting
electrical power before working on the motor. Make sure the power
is off when checking each phase.

MAINTENANCE:

1.

There are no lubrication points, therefore, no lubrication is necessary.

Make sure the blade runs in the correct rotation.

Clean the outside of the fan motor as necessary.

DO NOT FORGET: THE POWER MUST BE OFF WHEN WORKING ON THIS UNIT.

YOU COULD BE INJURED.

1001AC
