15
Use Six M8 Screws
9mm Deep Thread
for Tray Mounting
6.3”
160mm
3.5”
89mm
1/4” NPT
Use Two M10 Bolts
for Mounting
9.8”
250mm
.4”
10mm
2.7”
68mm
1.3”
32mm
3.6”
92mm
5.12”
130mm
3.4”
87mm
3.6”
92mm
Speed Adjustment Screw
MODEL TP-40 DIMENSIONAL DRAWING
