MoTeC Appendices 71
Update Rate Summary
Device Input Type Maximum Update
Rate (per second)
ADL3 Analogue Voltage Inputs 1000
ADL3 Analogue Temperature Inputs 1000
ADL3 Digital Inputs and Speed Inputs 100
ADL3 RS232 and CAN Communications 50 max *
ADL3 CAN comms fast receive 1000
ACL RS232 Communications 200 *
ACL General CAN communications 200 *
CDL3/C125 Analogue Voltage Inputs 500
CDL3/C125 Analogue Temperature Inputs 500
CDL3/C125 Digital Inputs and Speed Inputs 100
CDL3/C125 RS232 and CAN Communications 50 max *
CDL3/C125 CAN comms fast receive 500
VIM AV Fast Inputs 5000
VIM AV Differential Voltage Inputs 1000
VIM AV High Resolution Inputs 500
VIM AV Special Inputs 2000
VIM Speed Inputs 100
ADL2/SDL
Analogue Voltage Inputs 1 to 4
(ADL2/SDL) and 11 to 14 (ADL2)
1000
ADL2/SDL Other Analogue Voltage Inputs 500
ADL2/SDL Analogue Temperature Inputs 500
ADL2/SDL Lambda Inputs 100
ADL2/SDL Digital & Speed Inputs 100
SDL Internal G Sensors 100
E888
Thermocouple Inputs
(First Device / Second Device)
100 / 50
E888/816
Analogue Voltage & Digital Inputs
(First Device / Second Device)
200 / 50
