66 Appendices
MoTeC
Wiring
This section provides reference material about the Display Logger's connector
and wiring requirements.
Connector
C125 connector
34 pin connector
Mating connector
34 pin AMP connector #65044
Wire Specification
Wire
Wire to suit Display Logger connector: 22# Tefzel, Mil Spec : M22759/16-22
M22759/16 Wire Ratings (for various wire gauges)
Insulation Material: Tefzel
Conductor: Tin Plated Copper
Voltage Rating: 600 V
Maximum Temperature: 150
°C
Wire Gauge
[AWG]
Cross
Sectional Area
[mm2]
Max Current
at 100
°C
Ambient [A]
Resistance
[ohm/m]
Resistance
[ohm / 1000 ft]
22 0.38 5 0.045
14.0
20
0.61
6
0.028
8.5
18 0.96 9 0.018
5.5
16
1.2
12
0.014
4.3
14 1.9
18 0.009
2.7
12
3.0
24
0.006
1.8
