4
B / W
↲
BURST ON/OFF
IR OPTIMIZER ON/OFF
MODE AUTO/CENTER
LEVEL 0~31
EXT1 & EXT2 for external trigger signal. (Enable EXT2 for IR LED optimizer function )
PRIVACY OFF
ON AREA SEL 1/4、2/4、3/4、4/4
TOP/BOTTOM 0~244
LEFT/RIGHT 0~378
COLOR 0~8
TRANSP
0.00/ 0.50/ 0.75 /1.00
MOSAIC ON / OFF
MOTION DET OFF
ON
↲
DETECT SENSE 0~127
BLOCK DISP OFF /ON / ENABLE
↲
MONITOR AREA ON/OFF
AREA SEL 1/4、2/4、3/4、4/4
TOP / BOTTOM
0~288
LEFT / RIGHT 0~468
NR
↲
NR MODE Y/C ; Y ; C ; OFF
CAMERAID OFF/ON↲
SYNC INT
LANGUAGE ENGLISH
/日本語 / DEUTSCH / FRANCAIS / PYCCKNŇ / PORTUGUÊS / ESPAŇOL
CAMERA RESET
‹ Sub-menu Brief Description
SUB-MENU DESCRIPTION
LENS Select and set the type of your lens: DC Driver, Video Driver or board lens.
SHUTTER / AGC Select “AUTO” to allow the camera to act automatically when the light condition of the
environment changes. Select “MANUAL” to fix the shutter and AGC modes of the camera
no matter how the light condition of the environment changes.
WHITE BAL Process the current image to retain color balance over a color temperature range.
BACKLIGHT Adjust the image to compensate for an area that is overpowered by brightness because of
excessive light.
“BLC” is to automatically adjust the level of the light to show more details in the dark
environment. And the “HLC” is to mask extremely bright areas.
PICT ADJUST Adjust the color of the pictures in, for example, brightness, contrast, sharpness and hue.
ATR D-WDR to increase the image recognized capability of the overexposed and dark areas.
PRIVACY Mask areas that should be not visible.
DAY / NIGHT Set the night surveillance mode to color or B/W.
NR Reduce noise by separating luminance (Y) and chrominance (C) settings.
CAMERA ID Set the title of the camera.
LANGUAGE Select the language of the menu on-screen display.
CAMERA RESET Press ↲ to restore all settings to their factory default values.
