2
‹ Installation Warning:
1. Please DO NOT USE SHIELD TWISTED PAIR WIRE. This will cause severe degradation on distance
performance and reduce the inherent interference immunity.
2. Please DO NOT have “bridge-taps” or loading coils in installation.
3. If the phone company provides the cable runs between buildings, make sure it’s “dry copper”.
4. Due to near-end cross talk, don’t send a transmitted and a received signal in the same wire bundle.
5. For safety, DO NOT put UTP cable in the same conduit as high-voltage wiring.
‹ Installation Notes:
1. Please use point-to-point Unshielded Twisted Pair wire, 24-16 AWG, Category 2, 3, 4, 5, or 6.
2. Please measure the wire distance, Use only transceivers that are designed for that distance.
3. Please make sure the pair of wires carrying the video signal is sent as a twisted pair (e.g. the
Blue-white/White-blue wires twisted together as a pair), not a “split-pair” (e.g. blue-white conductor, part of
one pair / orange-white conductor, part of another pair)
‹ Specification:
DM-650IR-F0312
Image Device Surge Protector
Image Device: 1/3“ SONY EXview HAD CCD II
(Effio-E)
Effective Picture Elements: PAL: 1024(H)x596 (V);
NTSC: 1028(H)x508(V) Video: Peak Inverse Blocking Voltage:
VPIB= 100V; Peak Pulse Current: Ipp=44A
Clamping Voltage: 10V @ Ipp= 5A
Power: Max. Energy: 3.6J @10/1000µs;
Clamping Voltage: 16.8KA(1 Time)
/8.4KA(2 Time) @8/20µs (1 Time);
Insulation Resistance:≧ 10000MΩ
Video
Horizontal Resolution: Color: 650TVL, B/W: 700TVL
Video System: NTSC/PAL (Optional)
Video Output: 1Vp-p output with RJ-45 connector; BNC
connector type (Option)
Illumination
Video Characteristic Minimum Illumination: Color: [email protected],
B/W: 0 Lux (IR LED on)
Gamma Characteristic: 0.45
Sync. System: Internal
S/N Ratio: More than 50dB (AGC Off)
Shutter Speed Control: AUTO (1/50(60) ~ 1/100,000
sec.)
Wide Dynamic Range: ATR Digital WD (ATR: Adaptive
Tone-curve Reproduction)
Lens & IR Illuminators
Lens: 2.8〜12 mm Vari-focus Lens
Infrared Luminary: 30pieces 12µ 850nm for
day & night application
Transmission Distance
OSD Menu Setting Transmit Video / Power up to 300 meters via Cat.
5 or better UTP cable
Flicker Less: ON/OFF
Gain Control: Auto (4 steps)
Dynamic Noise Reduction: 2D
Motion Detection: ON / OFF (24x16 Zones)
Day/Night Mode: Color / B&W / AUTO / Ext.
Back Light Compensation: HLC / BLC / OFF
Privacy Mask: ON / OFF (8 programmable mosaic zones)
Control Parameters: Menu OSD (With an optional OSD
cable control)
White Balance: ATW / PUSH / USER define / ANTI CR /
MANUAL / PUSH LOCK
Housing
Vandal resistant housing with 3-Axis bracket
Dimension/Weight
ψ 101mm x 101 mm (H) / 0.82Kg
Operation
Power Consumption: IR ON: DC
24V/150mA max, IR OFF: DC 24V/25mA.
Operation: Temperature -10°C ~ 50°C; Humidity
20% ~ 80% RH
