PARTS LIST FOR 250P INDEX DRIVE (STANDARD CONFIGURATION)
ITEM NO. PART NUMBER DESCRIPTION
1 ...................................................... 24C17959011002 HOUSING 2.75 C.D.
........................................................ (OUTPUT HORIZONTAL EVEN W/INPUT)
........................................................ 24C17959011002 HOUSING 2.75 C.D.
........................................................ (OUTPUT VERTICLE)
........................................................ 24L17832011002 HOUSING 2.75 C.D.
........................................................ (OUTPUT HORIZINTAL/OVER INPUT)
........................................................ 24J21358011002 HOUSING 2.75 C.D.
........................................................ (OUTPUTHORIZINTAL/UNDER INPUT)
........................................................ 24C17959021002 HOUSING 3.25 C.D.
........................................................ (OUTPUT HORIZONTAL EVEN INPUT)
........................................................ 24C17959021002 HOUSING 3.25 C.D.
........................................................ (OUTPUT VERTICLE)
........................................................ 24L17832021002 HOUSING 3.25 C.D.
........................................................ (OUTPUT HORIZONTAL/OVER INPUT)
........................................................ 24J21358021002 HOUSING 3.25 C.D.
........................................................ (OUTPUT HORIZONTAL/UNDER INPUT)
2 ...................................................... CAM, (SPECIFY NUMBER OF STOPS AND
........................................................ INDEX TIME, CONTACT CAMCO FOR
........................................................ ASSISTANCE, ORDER IN MATCHED SETS)
3 ...................................................... 24B08867004006 FOLLOWER WHEEL 6 HOLE, 5/8” FOLLOWER
........................................................ 24B08868004008 FOLLOWER WHEEL 8 HOLE, 5/8” FOLLOWER
........................................................ 24K11871004002 FOLLOWER WHEEL (FOR OSCILLATORS)
4 ...................................................... 24B08897007002 INPUT SHAFT DBL EXT (W/O REDUCER)
........................................................ 24B17627007001 INPUT SHAFT SGL EXT (W/O REDUCER)
........................................................ 81B19913007001 INPUT SHAFT SGL EXT (FOR R200 RED.)
........................................................ 24K12226007002 INPUT SHAFT DBL EXT (FOR R200 RED.)
5 ...................................................... 24B17628008001 OUTPUT SHAFT SGL EXT
........................................................ 24B08865008002 OUTPUT SHAFT DBL EXT
6 ...................................................... 24B17670003112 CARTRIDGE CLOSED ECC
7 ...................................................... 24B17669003111 CARTRIDGE CLOSED OUTPUT
........................................................ 24B17668003512 CARTRIDGE OPEN OUTPUT
8 ...................................................... 24B17958003122 CARTRIDGE OPEN ECC
9 ...................................................... 95A26000480000 SHCS 1/4-20 X 2 1/2
10 .................................................... 95A33000010000 AIR VENT (BREATHER)
11* ................................................... 24A17961018800 SHIM, .002 THK
* ....................................................... 24A17961028800 SHIM, .005 THK
* ....................................................... 24A17961038800 SHIM, .010 THK
12 .................................................... 95A26003210000 SHCS 10-32 X 3/8
13* ................................................... 84D07329050000 OIL SEAL C/R 6204
14* ................................................... 24A17674018800 SHIM, .002 THK
* ....................................................... 24A17674018800 SHIM, .005 THK
* ....................................................... 24A17674018800 SHIM, .010 THK
15* ................................................... 86D7328060022 BEARING CUP A5144
16* ................................................... 86D07328060021 BEARING CONE A5069
17* ................................................... 86D07328070022 BEARING CUP A6157
18* ................................................... 86D07328070021 BEARING CONE A6075
19 .................................................... 95A33003010000 MAGNETIC PLUG
20 .................................................... NOT USED ON 250P
21 .................................................... 95A26005100000 SSS CUP PT 6-40 X 3/16
22 .................................................... 82B08417010002 CAM FOLLOWER 5/8 DIA.
........................................................ 82J13456000002 CAM FOLLOWER 3/4 DIA.
