3.5” 24-Port 6Gb/s SAS Expander Backplane 80H10341801A0
User’s Manual
Compatible SAS RAID Cards
How To Assemble On The HDD Cage
Step 1 : Attach 8 pcs right angle “ L “ shape metal bracket on the backplane by screws
Manufacture
Model Number
3Wware 9750-8I
MegaRAID 9260-8I
1680DI-IX20-16
52445
The maximum quantity of supported physical drives per SAS RAID Card is
depended on the capability of the SAS RAID card in the system. Refer to the
technical document or user guide provided by RAID card manufacturer.
