D - P O W E R
S E R I E S
D-POWER 05
120/230 V ~ 50/60 Hz 120 W
250 W / 4 Ω
xxxxx
D-POWER 1
120/230 V ~ 50/60 Hz 200 W
500 W / 4 Ω
xxxxx
USER MANUAL
D-POWER 05/1
P.12
3.3 Mains
3.3.1 Mains Supply
When mounting or connecting the amp always disconnect it from mains.
Only connect the D-POWER amplifier to an appropriate AC circuit and out-
let, according to the requirements indicated in the second line on the rat-
ing plate.
Rating plates for D-POWER 05 and D-POWER 1.
Mains current draw and power consumption at different mains voltages
with
1
∕
8
th of rated output power into 4 Ω load, both channels driven:
Measured with pink noise with crest factor of 12 dB to represent typical music signal.
Voltage Mains Frequency Current
Power Consumption
D-POWER 05
100 V
50/60 Hz
1,80 A
120 W
D-POWER 05
120 V
50/60 Hz
1,55 A
120 W
D-POWER 05
200 V
50/60 Hz
1,15 A
120 W
D-POWER 05
230 V
50/60 Hz
1,00 A
120 W
D-POWER 1
100 V
50/60 Hz
2,90 A
200 W
D-POWER 1
120 V
50/60 Hz
2,60 A
200 W
D-POWER 1
200 V
50/60 Hz
1,75 A
200 W
D-POWER 1
230 V
50/60 Hz
1,60 A
200 W
Mains current draw and power consumption @ 230 V, 50 Hz at different
output power levels with 4 Ω load, both channels driven:
Measured with pink noise with crest factor of 12 dB to represent typical music signal.
Operating condition
Mains
current
Power
consumption
Output
power
Idle (amplifier powered on)
0,3 A
23 W
0 W
32 W per channel
1 A
120 W
64 W
63 W per channel
1,6 A
200 W
126 W
125 W per channel*
2,7 A
350 W
250 W
200 W per channel*
3,9 A
530 W
400 W
*: duration limited by thermal limitation
