BatteryMINDer ® & Plus with SmarTECHnology ® Model 1500 Series
START-UP OPERATING INSTRUCTIONS
1. Place the positive ( RED ) connection on the positive battery
terminal.
2. Place the negative (BLACK) connection on the negative battery
terminal.
3. Plug in the BatteryMINDer.
4. Charging will be GREEN (flashing) (see item #5 in Table 2.) Reverse
leads if you do not see this.
TABLE 3
BatteryMINDer 1500 & BatteryMINDer Plus 1510 CHARGING STATUS
Power 100 - 240 VAC Power Connected
Battery Condition
Flashing: Battery Connected
Correctly
Solid: In Maintenance
(Charge Complete)
SPECIFICATIONS
BatteryMINDer 1500 & Plus 1510 1.5A @ 12VDC
INPUT 100-240 VAC • 50/60 Hz • 0.4A
MAINTENANCE CURRENT 0 - 1.5A
SIZE (mm) 100 L x 65 W x 30 H
WEIGHT 1.0 lbs.
TEMPERATURE COMPENSATION -20°C/-4°F to 50°C/122°F
