8
Parts List
Shop Presses
Service Parts
MODELS: IMP5506, IAP5506, IEP5506, IAP5513, IEP5513 & IEPD5513
SFA Companies 10939 N. Pomona Ave. Kansas City, MO 64153
Tel: 888-332-6419 * Fax: 816-891-6599
E-mail: [email protected] Website: www.bvahydraulics.com
Note: Not all components of the press are replacement items, but are illustrated as a convenient reference of location and
position in the assembly sequence.
Item
Part No. for Model
Description Qty
IMP5506 IAP5506 IAP5513 IEP5506 IEP5513 IEPD5513
1 N/A
Press Frame w/Winch and
Pump Brackets
1
2 N/A Bed Frame 1
3 400-002-003 Support Pin 2
4 IEP-001-004 Frame Base Channel 2
5 IEP-001-005 Lower Cross Member 1
6 400-002-006 Winch 1
7 400-002-007 Cable Sheaves (Pulley) 3
8 400-002-008 Cable 2
9 IEP-001-009 N/A Hand Pump Platform Bracket 1
10 N/A IEP-001-011 Air/Electric Pump Bracket 1
11 IEP-002-012 Cylinder Adapter Plate 1
12a H5506 N/A H5506 N/A
Single Acting Cylinder, 55 Ton
6” Stroke
1
12b N/A H5513 N/A H5513 N/A
Single Acting Cylinder, 55 Ton
13” Stroke
1
12c N/A HD5513
Double Acting Cylinder, 55 Ton
13” stroke
1
13 P2301 N/A Pump, Manual 1
14 N/A PA1500 N/A Pump, Air, 91.5 in 3 1
15 N/A PA3801 N/A Pump, Air, 232 in 3 1
16 N/A PEW0501T PEWM0501T Pump, Electric, 0.5 hp 1
17 300-002-016 N/A Pump Mounting Hardware Kit 1
18 N/A PEW01 Pendant Switch 1
19 CS3838 CS3838C CS3838 Hydraulic Hose 1*
20 CH38M Male Coupler 1*
21 GW4014 Pressure Gauge, 4”, Wet 1
22 CF3814 Gauge Adapter 1
23 AP55 Arbor Plates 1
* Qty 2 for IEPD5513 Double Acting Presses
